اسیلوسکوپ دیجیتالی یونی تی مدل UNI-T UTD 2052CL در فروشگاه عصرتولز…
| Model | UTD2025CL | UTD2052CL | |
| Bandwidth | 25MHz | 50MHz | |
| Channels | 2 | ||
| Sampling rate | 250MS/s | 500MS/s | |
| Rise time | <14ns | <7ns | |
| Memory depth | 25kpts | ||
| Waveform capture rate | >2, 000wfms/s | ||
| Vertical scale (V/div) | 1mV/div〜20V/div | ||
| Time base scale (s/div) | 10ns/div〜50s/div | 5ns/div〜50s/div | |
| Storage methods | Setup, waveform, bitmap | ||
| Trigger specifications | |||
| Frequency counter | 6 bits | ||
| Trigger types | Edge, pulse width, video (UTD2025CL), alternate | ||
| Level range | Internal | ±8div from screen center | |
| EXT | ±3V | ||
| Holdoff range | 80ns〜1.5s | ||
| Edge trigger types | Rise, fall, rise & fall | ||
| Interfaces | Pass/Fail (UTD2025CL), USB-OTG | ||
| General Characteristics | |||
| Power | 100V〜240V ACrms, 50Hz/60Hz | ||
| Display | 7-inch TFT LCD, WVGA (400×240) | ||
| Product color | White and grey | ||
| Product net weight | 2.2kg | ||
| Product size | 306mm x 147mm x 122mm | ||
| Standard accessories | Probe x 2 (1x, 10x switchable), power cord, USB interface cable, PC software CD | ||
| Standard individual packing | Carton box | ||
