Description |
UT658A |
UT658C |
UT658DUAL |
UT658LOAD |
| Input & Output ports (Type A) |
|
√ |
|
√ |
√ |
| Input & Output ports (Type C) |
|
|
√ |
√ |
|
| Data/charging protocol |
|
2.0/3.0 |
2.0/4.0 |
2.0/(3.0/4.0) |
2.0/3.0 |
| Voltage range |
4~24VDC, resolution: 0.01V |
√ |
√ |
√ |
√ |
| Current range (Type-A) |
0.05~3ADC, resolution: 0.01A |
√ |
|
√ |
√ |
| Current range (Type-C) |
0.05~5ADC, resolution: 0.01A |
|
√ |
√ |
|
| Capacity |
0~99999mAh, resolution: 1mAh |
√ |
√ |
√ |
√ |
| Energy |
0~1000Wh |
√ |
√ |
√ |
√ |
| Circuit equivalent resistance measurement |
1~480Ω |
√ |
√ |
√ |
√ |
| USB data cable voltage (D+, D-) |
0~3.3V |
√ |
√ |
√ |
√ |
| Data storage |
10 sets |
√ |
√ |
√ |
√ |
| Electrical load (UT658LOAD only) |
0.5A, 1A, 2A, 3A (Max power: 60W) |
|
|
|
√ |
| Maximum recording time |
99h, 59min, 59sec; resolution: 1s |
√ |
√ |
√ |
√ |
| Fast charge protocol (Type-A) |
QC 3.0 fast charge protocol |
√ |
|
√ |
√ |
| Fast charge protocol (Type-C) |
QC 4.0 fast charge protocol |
|
√ |
√ |
|
| General Characterisitics |
| Product color |
White |
| Product net weight |
UT658A/C: 50.6g; UT658DUAL: 65.8g; UT658LOAD: 114.4g |
| Product size |
UT658A/C: 93mm x 45mm x 13mm; UT658DUAL: 93mm x 55mm x 13mm;UT658LOAD: 122mm x 53mm x 27mm |
| Standard individual packing |
Gift box, English manual |
| Standard quantity per carton |
60pcs |
| Standard carton measurement |
UT658A/C/DUAL: 280mm x 220mm x 225mm; UT658LOAD: 320mm x 300mm x 225mm |
| Standard carton gross weight |
UT658A/C: 4kg; UT658DUAL: 5.5kg; UT658LOAD: 9kg |
