Specifications |
UT695D-10 |
Optical power meter |
Wavelength range |
800nm~1700nm |
Calibrated wavelength |
850nm, 980nm, 1300nm, 1310nm, 1490nm, 1550nm, 1625nm, 1650nm |
Measurement range |
-70~3dBm |
Uncertainty |
±5% |
Display resolution |
Linear: 0.1%, logarithmic: 0.01dBm |
Connector |
FC/SC/ST |
Detector type |
InGaAs |
Visual fault locator |
Wavelength |
650nm±10nm |
Power |
10mW (measurable optical fiber length: approximately 8~10km) |
Mode |
Continuous/Pulse |
Connector |
FC/SC/ST |
Flashlight |
√ |
LAN cable sequence test |
Line sequence measurement (LED1~8, LED_G) |
General Characteristics |
Power |
1050mAh rechargeable battery |
Display |
42mm x 33mm |
Product color |
Red and grey |
Product net weight |
168g |
Product size |
132mm x 68mm x 31mm |
Standard accessories |
USB cable |
Standard individual packing |
Gift box, English manual |
Standard quantity per carton |
10pcs |
Standard carton measurement |
305mm x 270mm x 130mm |
Standard carton gross weight |
About 2.7kg |
